Bio-Suction Pump (아스피레이터)
Model JSBS-5000 Bio-Suction is an economical, compact and portable solution for aspirating tissue culture samples, aqueous solutions, buffers, culture media residual suction. Two stage oil-free piston pump provides a high flow rate and powerful vacuum aspiration. 4000 cc autoclaveable glass suction bottle with over flow protection stopper protects liquid ingested into the pump system which may lead to the valve failing or a diaphragm rupturing. Pump automatically shut down when full and a hydrophobic PTFE inline filter further protects the pump from aerosol ingestion. Hands free foot pedal switch provides convenient On/ Off operation. Built-in silencer provides comfortable noise-free operation
 |
download_catalog_bio_suction_pump.pdf |
Specifications
|
Pumping Capacity |
JSBS-3000 20 liter/min JSBS-5000 40 liter/min. |
|
Ultimate Vacuum |
650 mmHg (-0.08 Mpa ABS) |
|
Bottle Capacity |
4000 cc |
|
Pump Control |
ON / OFF / Foot Pedal Switch |
|
Material |
Body : Epoxy Powder Coated Steel |
|
|
Bottle : Glass |
|
Utility |
50 mm hydrophobic PTFE Disc Filter |
|
|
Silencer |
|
|
Portable carrying handle |
|
Safety |
Automatic pump cut-off when full bottle |
|
Electric |
220±10% VAC 50/60Hz 1-Phase |
|
Plug config. |
CEE 7/7 Schuko or BS-1363 |
Models
|
Art No. |
JSBS-3000 |
JSBS-5000 |
|
|
Pumping Capacity |
20 liter / min. |
40 liter / min. |
|
|
Ultimate Vacuum |
650 mmHg (-0.08 Mpa ABS) |
||
|
Collection Bottle |
|
||
|
|
Capacity |
4000 cc |
|
|
|
Material |
Glass Bottle /w cap |
|
|
|
Utility |
Cap with overflow protection cut-off level sensor |
|
|
|
|
Inlet / Outlet fitting /w cap |
|
|
Pump Control |
On/ Off / Foot Pedal |
||
|
Safety |
∅50 mm hydrophobic inline PTFE filter protects aerosol ingestion |
||
|
|
Automatic pump shut off when bottle is full |
||
|
Accessories included |
Main body built-in vacuum pump system |
||
|
|
Collection reservoir bottle |
||
|
|
∅50 mm hydrophobic inline PTFE filter |
||
|
|
Foot Pedal |
||
|
|
Silencer |
||
|
|
Silicone Tubings |
||
|
Dimensions |
240 x 370 x 330 mm |
250 x 400 x 330 mm |
|
|
Electric Requirement |
220VAC 50/60Hz 1P |
||
|
Power Plug |
CEE 7/7 Schuko or BS-1363 |
||
Features
|
Control |
|
Vacuum Pump On / Off / Foot Pedal Overflow cut-off
|
|
Construction |
|
Durable epoxy powder coated metallic casing Removable 3000 cc glass suction bottle
|
|
Safety |
|
Overflow Cut-ff OVER CURRENT CUT-OFF : Fuse
|
Ordering Information
|
Art No. |
Descriptions |
Capacity |
Elec. Req. |
Net Wt. |
Ship Wt. |
|
JSBS-3000 |
Bio-Suction Pump |
20 liter/min |
220 VAC 50/60 Hz |
7.3 kg |
8.5 kg |
|
JSBS-5000 |
Bio-Suction Pump |
40 liter/min |
220 VAC 50/60 Hz |
10.8 kg |
12.0 kg |
